R4-45 Large Mobile Block Making Machine
The largest of the 45-second mobile machines, with a 3.7 kW drive for higher output on standard bricks and hollow blocks.
Power3.7 kWMoulding cycle45 sWeight750 kg
Indicative priceEXW US$1,290Ex-works China. Freight, packing and duties are quoted per destination.
Key features
- 3.7 kW drive for heavier mould boxes and multi-cavity patterns
- Highest standard-brick output of the 45-second range
- Mobile chassis with a wider footprint for stability under load
- Custom mould box available for non-standard block profiles
Quick answer
The R4-45 is the largest of the 45-second mobile machines, producing about 12,000 standard bricks or 1,800 hollow blocks in an eight-hour shift. Its 3.7 kW drive is sized to carry heavier and multi-cavity mould boxes, and the wider 1,250 × 1,350 mm footprint keeps it stable under that load.
How many blocks does the R4-45 produce per shift?
About 12,000 standard bricks (240 × 53 × 115 mm) or 1,800 hollow blocks (390 × 190 × 190 mm) in an eight-hour shift, at one block every 45 seconds.
Why does the R4-45 need a bigger motor than the R2-45 and R3-45?
The 3.7 kW drive is specified for heavier and multi-cavity mould boxes rather than for raw speed — the cycle stays at 45 seconds. The R2-45 and R3-45, which take a single steel mould box, run one 1.1 kW vibration motor.
What power supply does the R4-45 need?
380 V three-phase or 220 V single-phase, drawing 3.7 kW.
What does the R4-45 cost and what is included?
EXW US$1,290 including one steel mould box. A customised mould box for non-standard block profiles is US$450, higher than on the smaller machines because of the larger mould size.
Specification
Factory figures for the R4-45. Confirm the final configuration on your quotation — options listed here are quoted separately.
R4-45 — technical data
Machine
| Overall size | 1,250 × 1,350 × 1,550 mm |
|---|---|
| Power | 3.7 kW |
| Voltage | 380 V / 220 V |
| Moulding cycle | 45 s |
| Machine weight | 750 kg |
Output per shift
| Standard brick 240 × 53 × 115 mm | 12,000 pcs |
|---|---|
| Hollow block 390 × 190 × 190 mm | 1,800 pcs |
Supply
| Included mould | 1 mould box |
|---|---|
| Customised mould | US$450 |
| Price | EXW US$1,290 |
Figures are factory data from the manufacturer's specification sheets and catalogue.
Where it is used
- Precast yards supplying brick to distributors
- Housing and commercial projects with a continuous block demand
- Producing both standard bricks and 390 × 190 × 190 mm hollow blocks
